Description
Molded of engineering grade non-metallic thermoplastic. Adjustable, no need to remove or relocate mounting screws to re-position the box. Slots retain slider plate and guide it in a straight motion. Internal rails guide slider plate for smooth mounting adjustability. 4 in Dia 2-3/4 in width, 25 cu-in volume, two 1/2 in knockouts. Internal steel, stud/wood screws. Fixture rating 50 lb. UL listed for 2 hrs fire resistive walls and ceilings.
Product Details
Manufacturer: Allied Moulded Products, Inc
Manufacturer’s Part Number: SB-CB
Show me more Ceiling Boxes
- Machine tapped fixture holes, adjustable mounting plate for additional substrate thickness
- Slots retain slider plate and guide it in a straight motion
- Internal rails guide slider plate for smooth mounting adjustability in wall substrates from 1/2 to 1-3/8 in thick and ceiling substrates from 1/2 to 1-5/32 in
- Square corner design allows easy wall cut-in
- Molded spline device holes for quick device screw installation in wall boxes and machine tapped threads for ceiling fixture support in round ceiling boxes
- Slider plate holds screws in ready position to enable contractor to mount boxes faster
- Fan support product has steel bracket and mounting bolts for secure paddle fan mounting
- Heavy-duty non-slip pad to ensure boand slider assembly solidly hold mounted position
- Tested to hold 50 lb hung on boto simulate power cord pull-out strength
- Multi-gang boxes consist of internal holding slots for LVP-2 low-voltage partitions and dual voltage applications
| Cable Entry | Clamp |
| Number of Knockouts | 2 |
| Cubic Capacity | 25 cu-in |
| Shape | Round |
| Material | Polycarbonate |
| Color | Beige/Tan |
| Width | 4 in |
| Depth | 2-3/4 in |
| Mounting Type | Screw |
| Specification Sheet | Click here to download |
| Line Drawing | Click here to download |
